AFC110

Size:Ø110mm(Ø4.33")



    AFC110 .pdf

    AFC1103D Object





    Model No. RATED
    VOLTAGE
    (V)    		 FREQUENCY
    (Hz)    		 RATED
    CURRENT
    (A)    		 INPUT
    POWER
    (W)    		 SPEED
    (RPM)    		 MAX. AIR PRESSURE MAX. AIR FLOW NOISE dB(A)
    @1M    		 QTY.
    inchH2O mmH2O CFM m3/min
    		AFC110385V2HB 220 50/60 0.27/0.30 60/70 1100/1200 0.20/0.28 5.0/7.0 424/459 12/13 52/54
    		AFC110495V2HB 220 50/60 0.40/0.50 90/105 1200/1300 0.22/0.30 5.6/7.5 600/636 17/18 56/58
    		AFC110535V2HB 220 50/60 0.40/0.50 90/110 1200/1300 0.21/0.30 5.4/7.5 707/742 20/21 56/58
    		AFC110625V1HB 115 50/60 0.90/1.15 100/125 1250/1300 0.24/0.31 6.1/7.8 813/848 23/24 57/58
    		AFC110625V2HB 220 50/60 0.45/0.57 105/130 1250/1300 0.24/0.31 6.1/7.8 813/848 23/24 57/58
    		AFC110685V2HB 220 50/60 0.50/0.60 102/126 1200/1300 0.28/0.36 7.2/9.2 919/954 26/27 56/58
    		AFC110897V2HB 220 50/60 0.60/0.80 136/175 1200/1200 0.29/0.37 7.4/9.5 1166/1166 33/33 58/58

    *The price is only for sample. Each item price is negotiable if the quantity is large.
      The currency is USD.
      The delivery fee is not included in the unit price.
